M-thermo heat conductive materials
About Our Products
M-thermo heat conductive material is a sheet of thermal conductive filler made by our paper making and processing technology. Although its specific gravity is about 1/2 of aluminum, it has heat dissipation performance equivalent or superior to that of aluminum foil. It is also flexible and does not crack or break, so it can be processed into various shapes.
- Application：
-
- For air conditioning
- For automobiles
- For building materials
- For home electronics
- For industrial use
- For information and communication
- Function：
-
- Electricity
- Thermal quality
Applications and Achievements
Examples of Achievements
Base paper for radiant air conditioning, thermal diffuser for floor heating
Lineup
| (単位) | S-8010 | S-12520 | S-6030 | S-15040 | |
|---|---|---|---|---|---|
| Flame retardancy | UL94 V-0 equivalent | ||||
| Basis weight | g/m2 | 100 | 200 | 300 | 400 |
| Thickness | μm | 65 | 130 | 220 | 230 |
| Density | g/cm3 | 1.5 | 1.5 | 1.4 | 1.7 |
| Thermal conductivity (Horizontal Direction)) |
W/(m・K) | 80 | 125 | 60 | 150 |
| Thermal conductivity (Vertical Direction) |
1.3 | 2.2 | 1.6 | 2.3 | |
| Tensile strength (MD) | MPa | 12 | 8 | 12 | 8 |
| Tensile strength (CD) | 9 | 6 | 11 | 7 | |
| Volume resistivity | Ω・cm | 3.0×10-3 | 3.3×10-3 | 3.2×10-3 | 1.4×10-3 |
